VT-20
Effortless Handling Designed to lift heavy items without bending down, reducing physical strain. Low Fork Arms The fork arms have a ground clearance of only 85 mm, allowing easy insertion under small carts for lifting. Stable Drive System Equipped with a rigid chain drive, providing strong stability without oil leakage. Built-in Battery The machine has a built-in battery that can be charged using a standard 110V household power supply. It can be used continuously for 10 hours without charging. Agile Movement The rear wheels feature 360-degree steering, enabling easy pushing and maneuvering while moving forward. Spec: *Mechanism Load Capacity: 150 kg
Key Points
- Reduce bending and lifting effort during material handling tasks.
- 85 mm low fork arms slide easily under small carts for fast lifting.
- Rigid chain drive provides stable lifting without oil leakage.
- Built-in battery charges from a standard 110V power supply and supports up to 10 hours of operation.
- 360-degree rear-wheel steering improves maneuverability in tight working areas.
- Mechanism load capacity: 150 kg.
Related Entities
VT-20 Lifter
Product Description
- Effortless Handling
Designed to lift heavy items without bending down, reducing physical strain. - Low Fork Arms
The fork arms have a ground clearance of only 85 mm, allowing easy insertion under small carts for lifting. - Stable Drive System
Equipped with a rigid chain drive, providing strong stability without oil leakage. - Built-in Battery
The machine has a built-in battery that can be charged using a standard 110V household power supply. It can be used continuously for 10 hours without charging. - Agile Movement
The rear wheels feature 360-degree steering, enabling easy pushing and maneuvering while moving forward.
Spec: *Mechanism Load Capacity: 150 kg
Applications
Where this product is typically used.
VT-20 Mobile Table-side Lifter
Designed for ergonomic lifting and short-range transfer tasks around table-side carts, workstations, and material handoff points.
Dimensional Specifications
VT-P20 Dimensions
| Dimension | Value |
|---|---|
| Overall width | 644 mm |
| Overall height | 814 mm |
| Fork width | 350 mm |
| Fork spacing | 170 mm |
| Overall depth | 405 mm |
| Maximum height | 870 mm |
| Minimum height | 85 mm |
| Lifting stroke | 748 mm |
| Body height | 714 mm |
